The versatile EloPOS System combines modern aesthetics, modular flexibility and commercial-grade reliability. Purpose-built for point of sale, EloPOS offers a 17-inch touchscreen display, choice of Intel’s 9th generation processors and an integrated expansion hub to connect the peripherals you need – whether a customer facing display, payment reader, printer, cash drawer, barcode scanner or scale. From traditional POS to self-service applications, EloPOS delivers the durability needed to survive continuous public use and is backed by Elo’s standard 3-year warranty.
|
Part Number |
Celeron, No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E548910 |
|
Enclosure Color |
Black |
|
Touch Technology & Capacity |
PCAP (TouchPro® Projected Capacitive) - 10 Touch |
|
Processor |
Celeron: Intel® Celeron® Processor G4900T (2M Cache, up to 2.9 GHz) |
|
Chipset |
Celeron Models: Intel H310 Express |
|
Graphics |
Celeron Models: Intel UHD Graphics 610 |
|
BIOS |
AMI |
|
Memory (RAM) |
Celeron Models: 4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB) |
|
Storage |
128GB M.2 SATA SSD, 80 TBW |
|
TPM |
2.0 |
|
Active Management Technology (AMT) |
Celeron Models: N/A |
|
Diagonal Size |
17'' diagonal, Active matrix TFT LCD (LED) |
|
Aspect Ratio |
5:4 |
|
Active Area |
13.3" x 10.64" / 337.9 mm x 270.3 mm |
|
Resolution |
1280 x 1024 @ 60Hz |
|
Number of Colors |
16.7 million |
|
Brightness (typical) |
LCD Panel: 250 nits |
|
Response Time-total (typical) |
5 msec |
|
Contrast Ratio |
1000:1 |
|
Viewing Angle |
Horizontal: ±85° or 170° total / Vertical: ±80° or 160° total |
|
USB Ports |
3 x USB 3.0 (1 on display head, 2 on I/O) |
|
Powered USB |
1 x 24V on I/O |
|
Ethernet Port |
1 x LAN RJ45 (Gigabit) |
|
Serial Ports |
2 x RJ45 |
|
Cash Drawer Port |
12V/24V Cash Drawer Port on I/O (EPSON Pinout, 24V default; selectable by internal switch) |
|
Wireless |
Wi-Fi 802.11 a/b/g/n/ac 2.4GHz and 5GHz |
|
Bluetooth |
Bluetooth 5.0 |
|
Additional Video Out |
1 x Full-function USB-C (Power up to 27W, USB 3.0, Display Port) |
|
Audio Ports |
1 x 3.5 mm headset jack |
|
Speakers |
2 x 2W internal speakers |
|
OS |
No OS |
|
Languages |
Windows 10 - 36 Language groups |
|
Power Supply |
External 24VDC universal-type power supply brick |
|
Power Consumption (Typical) |
ON: Celeron: 42W, i3: 63W, i5: 76W |
|
Dimensions |
With Stand: 15.49" x 12.83" x 8.71" / 393.5 mm x 325.9 mm x 221.3 mm |
|
Shipping Box Dimensions |
With Stand: 18.74" x 11.14" x 18.82" / 476 mm x 283 mm x 478 mm |
|
Weight (Unpackaged) |
With Stand: 14.77 lbs / 6.7 kg |
|
Weight (Packaged) |
With Stand: 19.8 lbs / 9.0 kg |
|
Operating Temperature |
0°C to 35°C / 32°F to 95°F |
|
Storage Temperature |
-20°C to 60°C / -4°F to 140°F |
|
Humidity |
Operating: 20% to 80% |
|
Energy Star |
Energy Star 7.1 |
|
Regulatory approvals and declarations |
UL/cUL, FCC, TUV, CE, CB, UKCA, Mexico NOM, RCM/R-NZ, VCCI, Argentina S-Mark, CCC |
|
MTBF |
50,000 hours demonstrated |
|
Mounting Options |
75mm VESA mount |
|
Warranty |
3-year |
|
Extended Service Options |
4 year warranty coverage - Elo P/N: E819598 |
|
Sealability |
Touchscreen sealed to sub-bezel |
|
Other Features |
Serviceable internal components. |
|
What's in the Box |
EloPOS System |
